JL Audio DSP TwK-88 8 Channel Car Audio Signal Processor

System Tuning DSP with 8-ch. Stereo RCA Inputs / 2 Digital (Optical and Coaxial) Inputs / 8-ch. Stereo RCA Outputs / 1 Digital Optical Output

The TwK® 88 is a state-of-the-art digital signal processor engineered to deliver world-class system tuning capabilities in an easy-to-use format. Equipped with an advanced 24-bit DSP processor, the TwK® 88 includes flexible input / output options, 80 total bands of equalization and powerful mixing tools. The included DRC-200 Digital Remote Controller offers dual level controls, toggles up to six presets, and has an LED indicator.

Control the TwK® 88’s entire feature set by connecting it to your PC via USB, using the companion TüN® Software interface.

• Power Supply Type: Regulated DC-DC SMPS
• Input Operating Voltage: 10 - 16 VDC
• Standby Current Draw: < 1.5 mA
• Operating Current Draw: 0.7 A
• Recommended Fuse Value: 1 A
• Input Channels: Eight
• Input Type: Line-level, Differential-Balanced
• Input Voltage Range: 250 mV - 7.1 V RMS
• Minimum Input Voltage: 10 mV RMS
• Input Level Setting: Eleven discrete selections from 250 mV - 7.1V RMS
• Output Channels: Eight
• Analog Output: Unbalanced, stereo RCA jacks
• Digital Output: Optical (Toslink) output (S/PDIF)
• Output Impedance: 450 Ω
• Latency: Analog - Analog: 5.425 mS, Analog - Optical: 5.470 mS, Optical - Optical: 4.860 mS, Optical - Analog: 4.805 mS
• S/N Ratio: 98 dB (A-Weighted, referred to 4V RMS Output)
• THD+N @ Rated Output: 0.02% (20 Hz - 20 kHz)
