JL Audio
JL Audio 12" W1 SUBWOOFER 300W @ 4 OHM JL12W1V3-4
JL Audio 12" W1 SUBWOOFER 300W @ 4 OHM JL12W1V3-4
Couldn't load pickup availability
12" W1 SUBWOOFER 300W @ 4 OHM
JL12W1V3-4
W1v3 12-inch Subwoofer (300 W, 4 Ω)
The 12W1v3 is a lightweight 12-inch driver with excellent performance capabilities at moderate power levels. It features moderate mounting depth with no pole-vent, so the rear of the motor structure can be placed directly against an enclosure boundary. Excellent excursion capability and linearity allow it to reproduce sub-bass with shocking extension and quality. Several of JL Audio's proprietary technologies enhance its performance and reliability.
The 12W1v3-4 is best used with amplifier power in the 75W - 300W range and is optimized to operate in a compact 1.10 cu. ft. (31.5 l) sealed enclosure.
| Speaker Size (in) | 12" |
|---|---|
| Style | Round |
| Impedance (Ohms) | 4 |
| Voice Coils | Single |
| RMS Power (W) | 200 |
| Peak Power (W) | 300 |
| Sensitivity (dB @ 1W/1m) | 86.1 |
| Frequency Response (Hz) | N/A |
| Features | DMA Optimised Motor Elevated Frame Cooling FCAM™ Cone Attach Method Vented Reinforcement Collar Insert Moulded Sub-Assembly Engineered Lead-Wire System |
| Height (cm) | 31.8 |
| Width (cm) | 31.8 |
| Depth (cm) | 15.6 |
| Protrusion (cm) | 1.9 |
| Mounting Depth (cm) | 13.7 |
| Mounting Hole Diameter (cm) | 28.1 |
| Grills | JLSGRU-12 (Sold Separately) |
| Recommended Amplifier | JLJD500/1 JLRD500/1 JLMX500/1 |
| Recommended Minimum Power Handling (W) | 75 |
| Recommended Maximum Power Handling (W) | 300 |
| Recommended Box Volume Sealed (Litres) | 31.15 |
| Recommended Box Volume Ported (Litres) | 45.3 |
| Brand | JL Audio |
| EAN | 699440996105 |
