JL Audio 10" W1 SUBWOOFER 300W @ 4 OHM JL10W1V3-4
JL Audio 10" W1 SUBWOOFER 300W @ 4 OHM JL10W1V3-4
Couldn't load pickup availability
10" W1 SUBWOOFER 300W @ 4 OHM
JL10W1V3-4
W1v3 10-inch Subwoofer (300 W, 4 Ω)
The 10W1v3 is an outstanding choice when space is very tight and amplifier power is moderate. It features shallow mounting depth (4.6 in. / 117 mm) and a compact motor structure, allowing it to comfortably fit in a lot of spaces where a typical 10-inch driver will not. Lacking a pole vent, the rear of the motor structure can be placed directly against an enclosure boundary. Excellent excursion capability and linearity allow it to reproduce sub-bass with shocking extension and quality. Several of JL Audio's proprietary technologies enhance its performance and reliability.
The 10W1v3-4 is best used with amplifier power in the 75W - 300W range and is optimized to operate in a compact 0.55 cu. ft. (15.57 l) sealed enclosure.
| Speaker Size (in) | 10" |
|---|---|
| Style | Round |
| Impedance (Ohms) | 4 |
| Voice Coils | Single |
| RMS Power (W) | 200 |
| Peak Power (W) | 300 |
| Sensitivity (dB @ 1W/1m) | 84.2 |
| Frequency Response (Hz) | N/A |
| Features | DMA Optimised Motor Elevated Frame Cooling FCAM™ Cone Attach Method Vented Reinforcement Collar Insert Moulded Sub-Assembly Engineered Lead-Wire System |
| Height (cm) | 26.7 |
| Width (cm) | 26.7 |
| Depth (cm) | 13.6 |
| Protrusion (cm) | 1.9 |
| Mounting Depth (cm) | 11.7 |
| Mounting Hole Diameter (cm) | 23 |
| Grills | JLSGRU-10 (Sold Separately) |
| Recommended Amplifier | JLJD500/1 JLRD500/1 JLMX500/1 |
| Recommended Minimum Power Handling (W) | 75 |
| Recommended Maximum Power Handling (W) | 300 |
| Recommended Box Volume Sealed (Litres) | 15.57 |
| Recommended Box Volume Ported (Litres) | 25.5 |
| Brand | JL Audio |
| EAN | 8714505045238 |
