Car Subwoofer Amplifier AMP bass JL Audio JD250.1D JD250/1D 1 x 250w RMS
Car Subwoofer Amplifier AMP bass JL Audio JD250.1D JD250/1D 1 x 250w RMS
Regular price
£209.99 GBP
Regular price
Sale price
£209.99 GBP
Unit price
per
JL AUDIO JD250/1D Mono Subwoofer Car Audio Amplifier
Monoblock Class D Subwoofer Amplifier, 250 W x 1 @ 2 Ω / 160 W x 1 @ 4 Ω - 14.4V
This rugged and reliable Class D monoblock uses a robust MOSFET power supply design that delivers rock-solid bass performance at a very affordable price.
Targeted specifically for subwoofer applications, the JX250/1D includes a low-pass filter with continuously variable cutoff frequency selection from 50-200 Hz. It also features a variable bass boost at 45 Hz. with up to 12 dB of boost and an optional remote boost control. Dedicated hi-level inputs are included, in addition to conventional low-level RCA inputs and a set of pass-through preamp outputs, making it easy to integrate with a variety of OEM and aftermarket head units.
Rated Continuous (RMS) Power @ 14.4 V
@ 4 Ω 160 W RMS x 1
@ 3 Ω 200 W RMS x 1
@ 2 Ω 250 W RMS x 1
@ 1.5 Ω N/A
Rated Continuous (RMS) Power @ 12.5 V
@ 4 Ω 125 W RMS x 1
@ 3 Ω 160 W RMS x 1
@ 2 Ω 220 W RMS x 1
@ 1.5 Ω N/A
General Specifications
Frequency Response 10 Hz - 150 Hz (+0, -1dB)
S/N Ratio, referred to highest rated power >97 dB below rated power (A-weighted, 20 Hz - 20 kHz noise bandwidth)
S/N Ratio, referred to 1 W >76 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
Damping Factor @ 4 Ω >1000 / 50 Hz
Damping Factor @ 2 Ω >500 / 50 Hz
THD+N @ Rated Power <1% @ 2 Ω per Ch.
Input Voltage Range @ RCA Inputs 200 mV - 4 V RMS
Input Voltage Range @ High-Level Inputs 2 V - 10 V RMS
Min.Copper Power / Ground Wire Gauge 8 AWG wire
Fuse Rating 30 A (AFS, AGU or MaxiFuseâ¢)
Signal Processing
Filter Mode(s) Low-Pass only
Filter Slope(s) 12 dB/octave
Filter Frequency Range 50 Hz - 200 Hz
Detented, Calibrated Filter Freq. Potentiometer No
Filter Defeat Function No
Infrasonic Filter none
Bass Boost EQ 0 to +12 dB @ 45 Hz
Output Polarity Switch No
Remote Subwoofer Level Control Optional (RBC-1)
Remote Bass EQ Boost Control No
Pass-Through Preamp Output Unbuffered
Physical Specifications
Table_Image
Height (H) 2.09 in / 53 mm
Width (W) 7.83 in / 199 mm
Depth (D) 7.68 in / 195 mm
Net Weight 4.6 lb / 2.09 kg
