MOSCONI PICO 4 / PICO 4 SA - 4 CHANNEL FULL RANGE CLASS D CAR AMPLIFIER

MOSCONI PICO 4 / PICO 4 SA - 4 CHANNEL FULL RANGE CLASS D CAR AMPLIFIER

£399.00 GBP
£399.00 GBP
Sale Sold out
Tax included.

OVERVIEW MOSCONI PICO 4 / PICO 4 SA

Four channel full range PWM amplifier with separate synchronized modulation. Up to 480 Wrms total power, bridgeable and 2-Ohm stable. Thus, the Mosconi PICO 4 masters any constellation: whether classic front-sub / front-rear concepts, doorboard, two subwoofers or subwoofers with dual voice coil. Ideal supplement to a Mosconi PICO DSP amplifier, but with the high-level and low-level input and its own filters, it can also be used universally.

  • Active crossover
  • Molex connectors
  • Compact design
  • High current efficiency
  • Crossover for semi active operation (Pico 4 SA)
  • Available as 24 Volt version (Pico 4 only)

TECHNICAL DATA MOSCONI PICO 4 / PICO 4 SA

OUTPUT POWER:

  • Output power RMS @ 4Ω:

    4 x 90 Watts

  • Output power RMS @ 2Ω:

    4 x 120 Watts

  • Output power RMS @ 4Ω:

    2 x 85 Watts + 1 x 245 Watts (bridged)

  • Output power RMS @ 4Ω:

    2 x 240 Watts (bridged)

SPECIFICATIONS:

  • Input voltage:

    0.3 - 20 V

  • Overall efficiency:

    > 75 %

  • Auto-On (only High Level):

    Off - BTL

  • Channel 1+2 Filter (HP) :

    Off – 80 Hz (12 dB/Oct)

  • Channel 3+4 Filter (HP/LP):

    Off – 80 Hz (12 dB/Oct)

  • Channel 1+2 Filter (HP):

    Off – 280 Hz (12 dB/Oct) - Pico 4 SA

  • Channel 3+4 Filter (HP/LP):

    Off - 220 Hz (12 dB/Oct) - Pico 4 SA

  • Dimensions:

    150 x 115 x 46 mm

  • Weight:

    1050 Gramm
